DS-330

Suitable for a wide range of services conditions.


Application

  • For use in general industrial applications including process services.
  • Lubricating liquids, aqueous solutions, chemicals, corrosives, some acids.

 View Sheet

Operating Conditions


  • Max. Operating Pressure : 10 kg/cm 2 *
  • Temperature Range : -55 to 100 *
  • Max. Rubbing Speed : 20 m/s

*(Depend on combination of materials)

Design Features/Benefits


  • Non-Clogging, Single Coil Spring will not run foul due to fluid contact.
  • Setting-length of spring can be held in position by impeller.
  • Easy to fit and can be repaired in the field to minimize downtime and lost revenue.
  • Sealing faces are precision lapped to provide effective performance with maximum seal life.



Standard Materials


  • Metal Parts : SUS 316
  • Spring : SUS 316
  • Rotary Face : Ceramic/Silicon Carbide/Tungsten Carbide
  • Stationary Face : Silicon Carbide/Tungsten Carbide/Carbon
  • Secondary Seals : Fluoroelastomer/Nitrile/Ethylene Propelene

*(Other configuration of materials also available on request)
